name: gflownets-intro-part2-20250915 class: title, middle ## Probabilistic inference with GFlowNets ### IFT 6760B A25 #### .gray224[September 15th - Session 4] ### .gray224[Introduction to GFlowNets II] .smaller[.footer[ Slides: [alexhernandezgarcia.github.io/teaching/mlprojects24/slides/{{ name }}](https://alexhernandezgarcia.github.io/teaching/gflownets25/slides/{{ name }}) ]] .center[ <a href="http://www.umontreal.ca/"><img src="../../../assets/images/slides/logos/udem-white.png" alt="UdeM" style="height: 6em"></a> ] Alex Hernández-García (he/il/él) .footer[[alexhernandezgarcia.github.io](https://alexhernandezgarcia.github.io/) | [alex.hernandez-garcia@mila.quebec](mailto:alex.hernandez-garcia@mila.quebec)] | [alexhergar.bsky.social](https://bsky.app/profile/alexhergar.bsky.social) [](https://bsky.app/profile/alexhergar.bsky.social)<br> --- ## Objectives of this session - Finalise the introduction of GFlowNets: - Flow networks - Flow matching objective function - Overview of basic results -- The goal is that at the end of the session: - You will be able to describe what flow networks are. - You will be able to explain why GFlowNets _work_. - You will have an intuition of how GFlowNets are trained and what are the basic results on simple problems. --- ## In the previous session... .references[ Emmanuel Bengio, Moksh Jain, Maksym Korablyov, Doina Precup, Yoshua Bengio. [Flow network based generative models for non-iterative diverse candidate generation](https://arxiv.org/abs/2106.04399). NeurIPS, 2021. ] - We described the original motivation and context of GFlowNets. - We established the typical problem setting for GFlowNets. - We traced connections with energy-based models, sampling (MCMC) methods and reinforcement learning. - We proved that RL or autoregressive approaches work well when the decomposition of samples has a tree structure. - But sampling gets biased towards "bigger" objects if multiple trajectories exist for a single sample. --- ## Today .references[ Emmanuel Bengio, Moksh Jain, Maksym Korablyov, Doina Precup, Yoshua Bengio. [Flow network based generative models for non-iterative diverse candidate generation](https://arxiv.org/abs/2106.04399). NeurIPS, 2021. ] - We will continue the study of the original paper. - Introduce flow networks and prove how they can enable sampling in the general DAG case. - Introduce the flow matching objective function to train GFlowNets. - Show a set of basic empirical results to demonstrate that GFlowNets work as expectred. --- ## Results ### Hyper-grid Experiments with a hyper-grid in 4D and length 8 ($8^4 = 4096$ states and samples), where trajectories start in a corner and increment each dimension one by one. .left-column-33[.center[]] -- .right-column-66[.center[]] --- ## Results ### Molecules Experiments with a fragment-based molecular generation task, with a sample space of $10^16$ and between 100 and 2000 actions from each state. The reward $R(x)^{\beta}$ is the binding energy of the molecule with with a target protein. .center[] --- ## Results ### Molecules .left-column[.center[]] -- .right-column[.center[]] -- .full-width[ .conclusion[GFlowNet samples more unique, high-scoring molecules than baseline MCMC and RL methods. The empirical reward density is higher than that of a reference data set.] ] --- ## Results ### Molecules .center[] --- ## Results ### Molecules .center[] --- ## Results ### 2D Grid .center[] --- name: title class: title, middle count: false ## Probabilistic inference with GFlowNets ### IFT 6760B A25 #### .gray224[September 15th - Session 4] ### .gray224[Introduction to GFlowNets II] .center[ <a href="http://www.umontreal.ca/"><img src="../../../assets/images/slides/logos/udem-white.png" alt="Mila" style="height: 6em"></a> ] Alex Hernández-García (he/il/él) .footer[[alexhernandezgarcia.github.io](https://alexhernandezgarcia.github.io/) | [alex.hernandez-garcia@mila.quebec](mailto:alex.hernandez-garcia@mila.quebec)] | [alexhergar.bsky.social](https://bsky.app/profile/alexhergar.bsky.social) [](https://bsky.app/profile/alexhergar.bsky.social)<br>
